Lutron MS7000

Moisture Meter + RS232

Model : MS‑7000

Measure moisture content over range 9% to 30%.
9 material species groups in memory, calibrations for about 150 different species of wood/timber are provided.
Built‑in self‑calibration circuit.
0 to 50 ℃ manual temp. compensation setting.
Microprocessor circuit assures maximum possible accuracy, provides special functions and features.
Super large LCD with dual display.
Heavy duty & compact housing case, designed for easy carry out & operation.
Records Maximum & Minimum reading with recall.
Data hold function to freeze the desired value on display.
Auto shut off saves battery life.
RS232 PC serial interface.
Built‑in low battery indicator.
Separate pin type moisture probe, easy operation & remote measurement.

Applications	For surveying buildings for dampness and for the rapid determination of the moisture content of wood/timber.
Principal	Used the 2 pins electrode to measure the conductive ability of the species, then convert to the reading of % “Moisture of Content”.
Default Memory for the species	9 material species groups in memory.
Circuit	Custom one‑chip of microprocessor LSI circuit.
Display	13 mm (0.5") super large LCD display, dual function meter’s display.
Measurement	Measure moisture content over range 9% to 30%.
Probe	Separate 2 pins moisture electrode.
Temperature Compensation	Manual temperature compensation of the meter in the range of 0 to 50 ℃.
Calibration	Built‑in self‑calibration circuit by push button on front panel.
Data Hold	By push button on front panel.
Memory Recall	Records Maximum & Minimum reading value.
Power off	Auto shut off saves battery life, or manual off by push button.
Sampling Time	Approx. 0.8 second.
Data Output	RS232 PC serial interface.
Operating Temperature	0 to 50 ℃ (32 ℉ to 122 ℉).
Operating Humidity	Less than 80% RH.
Power Supply	006P DC 9V battery or equivalent, recommend use alkaline or heavy duty battery.
Power Current	Approx. DC 6.5 mA.
Weight	330 g / 0.73 LB.
Dimension	Main instrument : 180 x 72 x 32 mm (7.1 x 2.8 x 1.3 inch). Moisture Probe : Round, 23 mm Dia. x 165 mm.
Accessories Included	Instruction manual ............... 1 PC. Moisture probe ................... 1 PC. Extra contact pins ............... 10 PCs. Hard Carrying Case ............... 1 PC.

* Appearance and specifications listed in this brochure are subject to change without notice.

Selling Unit	EACH
Model No	MS7000
Brand
Description	Moisture Meter + RS232
Categories	Test & Measurement Equipment Digital Test Equipment Analytical Meters
